DIY Linkable LED Lights
The Ledvance Linkable LED light is a cost-effective and scalable lighting solution. With a fully integrated design, there are no tubes to replace, making it a convenient choice for your lighting needs. It's also entirely do-it-yourself (DIY) friendly.
This versatile LED batten is perfect for indirect (hidden behind joinery), surface-mounted, wall-mounted, or ceiling installations. Each linkable LED light includes a power cord, linking cable, mounting clips and screws (as pictured above).
Choose between two lengths (600mm and 1200mm) and two colour temperatures (Neutral White 4000K and Daylight 6500K).
Save Energy. Benefit from over 50% energy savings compared to conventional fluorescent tube lighting. With a 15,000-hour lifetime and a 5-year warranty, you can trust the durability and longevity of this LED batten.
DIY Friendly. Installation is a breeze with the linkable design, eliminating the need for an electrician. You can plug them together to form a continuous lighting run. Alternatively, you can join them with the 25cm linking cable provided. Each linkable LED light also includes a 150cm power cord, mounting clips, and screws for a hassle-free setup.
Expandable. If you need to increase brightness in an area, simply add some additional lights. You can link up to 15 short battens or eight long battens together to create the perfect lighting configuration for your space. You can even connect a mix of long and short battens.
Daisy-chain up to 15 lights with the included flexible joining cable.
Two Lengths. You can customise your lighting setup with two lengths and two corresponding wattage options for maximum efficiency. The 600mm (2ft) unit consumes 6.5W, and the 1200mm (4ft) uses 13W. Each batten delivers an impressive 100 lumens of brightness per watt.
Compact Design. The slim and compact design measures 2.3cm wide and 3.4cm tall, making it an unobtrusive addition to any space. Rated IP20 for indoor use, this linkable LED light is suitable for a variety of applications, including:
- Cabinet, shelf or benchtop lighting
- Garage, workshop or shed lighting
- Shop window displays or signage lighting
- Back office and storage areas
- Building corridors and stairwells (where they are not emergency lights)
Specifications - Ledvance Linkable LED Batten
| Fitting Type | Full fixture DIY LED batten |
| Power Usage | 6.5W (600mm) or 13W (1200mm) |
| Voltage | 220-240 V AC |
| Lifetime | 15,000 Hours |
| Colour Temperature | 4000K (Neutral White) or 6500K (Daylight) |
| Light Output | 650 lumen (6.5W) or 1,300 lumen (13W) |
| Beam Angle | 100° |
| Dimmable | No |
| Dimensions | '4 Foot' = 1185mm x 20mm x 31mm '2 Foot' = 585mm x 20mm x 31mm (length x width x height) |
| IP rating | IP20 |
| Weight | 1200mm = 290 grams 600mm = 150 grams |
| Materials | Polycarbonate (PC) housing, diffuser and mounting clips. |
| Carton Quantity | 30 (this listing is for one batten) |
| Installation | Installation by anyone. Each batten includes a 150cm power cord with a 2-pin plug, a 25cm link cable, mounting clips, and screws. Multiple battens can be plugged directly into each other or connected with the flexible linking cable. |
| Product Identifiers | Ledvance Linkable Batten LDVAL BAT 600/1200 6.5W/13W 4000K/6500K 30X1 G4 AU (product name); 4099854114991, 4099854115011, 4099854115059, 4099854115073 (part numbers) |
| Further Details | Ledvance Linkable Batten Brochure (PDF) |
| Warranty | 2 Years |
Frequently Asked Questions
How do I turn them on or off?
If your power outlet is in a good spot, you can switch them on and off there. Otherwise, check out our timers, plugs, and remote sockets.
How do these linkable battens compare to other LED battens?
Unlike our other LED battens that require an electrician for installation, these linkable LED lights can be self-installed in most instances. This installation flexibility often more than makes up for the fact they are less bright than our other LED battens. But you may need to install more to achieve the same brightness levels. Here's how they compare to some other items in our range:
- Linkable (DIY) - up to 13 watts
- Slimline - up to 20 watts
- Tri Colour - up to 35 watts
- Weatherproof - up to 36 watts
What other options are available?
See our complete range of LED batten lights for more options. All our LED battens come as an integrated product, combining the light fitting and the light source into one unit. There are no separate tubes to fit now or replace in the future.
If you’d prefer to keep your existing light fittings and replace your fluro tubes, see our range of LED tubes.
