Vico LED Batten - Dual Wattage & Sensor

7 reviews

Size: 16W (665mm)
Price:
Sale price$110.00 Regular price$179.00
Stock:
13 in Stock   ✓ Next Day Dispatch

These lights are awesome! I have them in my garage. No more fumbling in the dark or not enough light. They switch on and off as programmed. - Christopher K. (Verified Buyer)

The LED Batten That Saves You Energy & Money

The enLighten Vico linear LED batten is packed with features to save you energy and money. These include:

  • Easy to configure microwave motion sensor - reduces energy consumption by up to 90%.
  • A dual wattage switch to optimise light levels and power usage.
  • Two size options - choose between '2 Foot' and '4 Foot' sizes.
  • Also available with emergency battery backup.

Enlighten Vico Batten Key Features & Applications

enLighten Vico Linear LED Batten - Key Features & Applications.

Configuring the Motion Sensor Is Easy

The included sensor allows the light fitting to dim down or switch off when no one is around. The microwave sensor sits behind the diffuser, so you can't even see it.

Here are the three modes of operation and main settings:

  1. On - When any movement is detected, the Vico switches to 100% brightness.
  2. Standby - After a set time with no movement (5 seconds, 30 seconds, 3 minutes, or 10 minutes), it goes into a standby mode of 20% brightness.
  3. Hold or Off - The fitting can stay in this standby mode indefinitely until motion is detected again. Or, it can switch off completely after a further 0 seconds, 90 seconds, or 3 minutes.

    These settings are controlled by a series of 'dip switches' located behind the diffuser (front cover). You can select your preferred settings at the time of installation or change them again in the future if needed.

    Vico Linear LED Batten in Car Park

    The Vico LED Batten is ideal for any area with intermittent usage. They're used in car parks, emergency exit stairwells, and other areas that need dependable 24/7 lighting.

    NEW - 'Eco Dim' Dual Wattage Switch

    The Vico now has an 'Eco Dim' switch which reduces power and light output by 50%. Therefore, a single Vico fitting can replace either twin-tube or single-tube fluoro light fittings.

    Model Full Power Mode Half-Power Mode
    1200mm 7W (Standby) to 30W (On) 3.5W (Standby) to 15W (On)
    600mm 5W (Standby) to 16W (On) 3W (Standby) to 8W (On)

    The power consumption of the emergency model (with battery charging) is up to 2W higher.

    Specifications - enLighten Vico LED Linear Batten

    Fitting Type Complete light fitting
    Maximum Power Usage 16W ('2 Foot') or 30W ('4 Foot')
    Voltage 220 - 240V AC
    Lifetime 100,000+ hour rated LEDs
    Colour Temperature 5000K (Cool White / Daylight)
    Material Polycarbonate
    Light Output 2,215 lumens (600mm) or 4,220 lumens (1200mm)
    Sensor Type Microwave
    Sensor Override Yes, see the installation instructions below for all settings
    Ratings IP65 (waterproof) and IK10 (highest level of impact resistance)
    Dimensions 665mm (length) x 110mm (width) x 86mm (depth),
    1270mm (length) x 110mm (width) x 86mm (depth)
    Weight 1.8kg (600mm), 2.9kg (1200mm)
    Battery Backup No - see here
    Installation To be completed by an electrician. 3 wire terminal block inside for electrical connection. Surface mounting brackets included.
    Product Identifiers BL06S, BL12S
    Warranty 5 Years
    Further Details Spec Sheet (PDF), Installation Instructions (PDF)

    Vico LED Batten Dimensions

    Dimensions of the nominal 600mm (2 Foot) and 1200mm (4 Foot) Vico LED battens.

    Frequently Asked Questions

    How does the Vico's electricity usage compare to old fluoro tubes?

    The table below shows how the power usage of the Vico is up to around 90% lower than old fashioned fluorescent tube battens. But don't forget, savings can be even higher if you set the light to turn off completely after a certain amount of time.

    Model Old Twin Fluro's Vico LED (On) Vico LED (Standby)
    1200mm 90W 30W 7W (92% less power)
    600mm 45W 16W 5W (89% less power)

    Fluro tube usage is based on 2 x 18W T8 tube and 2 x 36W T8 tube fittings and includes losses in the ballast.

    Do you sell an LED batten without a motion sensor?

    Yes - if you do not require a motion sensor, see our complete range of LED batten lights.
